HD-F801-2 Gas Chromatography

Name: HDF8012 Gas Chromatography
Brand: HAIDA
Price: 1 USD

Buy cheap HD-F801-2 Gas Chromatography product

Brand Name : HAIDA

Model Number : HD-F801-2

Certification : ISO 9001:2000; ISO 9001:2008

Place of Origin : Guangdong, China (Mainland)

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash,escrow

Supply Ability : 30 Sets per Month Haida

Delivery Time : 5-8 work days

Packaging Details : ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man

Loading Frequency : can be set

Test Stroke : 1000mm

Impact Height : 152mm

Warranty : 1 year

Backrest Load : 400N

Test Results : Output by built-in printer

Temperature Resolution : ±0.1℃

Counter Range : 0-99999 times

Handrail Loading Force : 250N

Flame Height : 35mm

Induction Mode : Precision load cell

Machine Specifications : 6.8 m × 2.6 m × 2.4 m

Dimensions : 3.5m x 2.4mx2.4m

Air Pressure : 4 ~ 7 bar

Position Resolution : min. 0.2 mm

Contact Now

HD-F801-2 Gas Chromatography

A whole set: Automatic thermal desorption apparatus+ Gas Chromatography+Hydrogen generator +Air generator

Technical Parameters of Gas Chromatography

Furnace size	28x 30 x18cm
Temperature range
Temperature setting	1℃
programmed heating rate	0.1℃
Maximum heating speed	120℃/ min
Temperature stability	0.01℃when the ambient temperature changes by 1℃
Programmed temperature rise	7-step programmed temperature rise
Loss compensation of operable column	dual channel
Power supply	220V±10%,2500W (maximum)
Volume	57x 55 x48 cm
Weight	around 50kg

Technical Parameters of Detector:

Hydrogen flame ionization detector (FID)
Maximum operating temperature	400℃
Detection limit	≤5 x 10-12g / S
Drift	≤5 x 10-13a / 30min
Noise	2 x 10-13a
Dynamic linear range	≥107
Thermal conductivity cell detector(TCD)
Maximum operating temperature	400℃
Sensitivity	≥10000 mv.ml/mg[n-C16]
Drift	≤100uv / 30mi
Noise	≤20ua
Dynamic linear range	≥104
Electronic capture detector (ECD)
Maximum operating temperature	350℃
Detection limit	≤6×10-15 g / ml (γ - 666)
Drift	≤50uv / 30min
Noise	≤20uv
Dynamic linear range	≥104

Technical Parameters of Automatic thermal desorption apparatus

Temperature control range of sample area	5℃-400℃; Heat power:200W
Temperature control range of valve injection system	5℃-180℃; Heat power:60W
Sample transfer line temperature control range	5℃-200℃; Heat power:40W
Temperature Control Accuracy	< ±0.1℃
Temperature control gradient	< ±0.1℃
Desorption recovery	> 95%
Analog sampling flow	100ml/min
Blowback cleaning flow	0~200ml/min
Machine Size and Weight( L x W x H)	400x170x300mm,Around 12kg
